S7 String Handling Bug: Troubleshooting with PLC4X

Hey guys, let's dive into some interesting quirks I've bumped into while wrangling S7 STRING data using the PLC4X S7 driver. Specifically, I've been poking around with a S7-1500 PLC and version 0.13.0-SNAPSHOT (though I've verified the same behavior in more recent versions). Get ready for some head-scratching moments, because we're about to uncover some intriguing issues related to how the driver handles string data.

The Mystery of the Max STRING Length

Alright, first things first: we're talking about STRING data types. In the world of S7 PLCs, a STRING can have a maximum length of 254 characters. This includes the characters themselves and, crucially, two bytes that store the length information. That's how the PLC knows how long your string actually is. Now, here's where things get a bit… wonky. The S7 driver, specifically in the StaticHelper class (check it out here), has defined a maximum string length of 250. This might not seem like a big deal at first, but it causes some significant problems when you start playing with strings longer than 250 characters.

Let's paint a picture: Imagine you've configured a tag in your PLC that's designed to hold a string up to the maximum 254 characters. Now, you try to interact with this tag using the PLC4X driver. Because the driver thinks the maximum length is 250, it truncates the data when sending it to the PLC. The driver essentially lies in the packet, telling the PLC it's sending a certain number of bytes when it's actually sending fewer. The PLC, being the smart cookie it is, notices this inconsistency and throws back a 0x07 Data type inconsistent error. Ouch.

This behavior is obviously a big pain in the butt. You can work around it by configuring your PLC tag to have a max length of 250, but that's far from ideal. You're now restricted in your string lengths, and you don't get the full flexibility the PLC offers. This is where the first question comes in: why did the developers of the S7 driver set the max length to 250 instead of 254? Is it a misunderstanding of how strings are stored in the PLC, or is it due to some other limitation or design decision? Understanding the reasoning behind this could help us fix or mitigate the issue.

Furthermore, this truncation isn't just a minor inconvenience. It potentially limits the types of applications you can build, as you must always be mindful of string lengths. Think about applications where dynamic data is written to the PLC. Maybe you're writing order numbers, names, or other text-based information. If the string handling isn't robust, you could experience all sorts of weird issues and errors when the data exceeds the driver's internal limitations. This is all the more reason why having a reliable and flexible string handling mechanism is crucial for the reliability and usability of any PLC integration project.

The Quirks of S7StringVarLengthTag

Now, let's move on to another issue with how the S7 driver handles STRING data. There's a particular tag type called S7StringVarLengthTag. When using this, the driver's behavior gets a little… restrictive. It essentially limits you to writing strings whose length is determined by whatever is already stored at the PLC's address. If the tag is currently empty, you're out of luck. The driver won't let you write anything to it.

Here’s how it works: the driver reads the length of the string currently stored in the PLC. It then trims the string you're sending to match that length. If you try to write a string that's shorter than the one currently stored, it gets trimmed to the shorter length. That can be confusing, but the real kicker is that if the PLC tag is empty, the driver won’t let you write anything to it. It’s like the driver needs a pre-existing string to work with. It's a bit like a self-fulfilling prophecy – the PLC tag must contain a string before it can receive a string written by the driver.

This limitation is strange, guys. You'd expect the driver to simply take the string you provide and write it, respecting the defined maximum length (254, in the PLC's case). Why would the driver insist on matching the length of a string that’s already there? This functionality drastically limits the flexibility and ease of use. It also makes it difficult, if not impossible, to initialize string values in the PLC from your application. You'd need a workaround to ensure the tag has an initial value, which is not only more work but also increases the risk of error and introduces unnecessary complexity.

This all leads to the big question: What's the use case for this type of functionality? What scenario necessitates a driver that so tightly couples the string writing process with the initial state of the PLC tag? Is there some specific advantage, or is it a design choice that could benefit from a fresh look? I'm not entirely sure, but the limitations introduced by this behavior make me want to ask some serious questions about its practical application.

Version and Protocol Details

For reference, the version I'm using is v0.13.0-SNAPSHOT. I've been testing this against an S7-1500 PLC. The protocol in question is obviously S7, as this is an issue related to the S7 driver of PLC4X.

  • Programming Languages: This is specifically about the plc4j library.

Conclusion and Next Steps

So, there you have it, guys. Two intriguing bugs I've uncovered while working with the S7 driver and STRING data types. The max length truncation and the limitations of S7StringVarLengthTag are issues that can significantly impact the usability of PLC4X in real-world applications. These issues not only introduce limitations but can also be quite confusing, making it harder to troubleshoot and maintain your PLC integration projects.

If you're a PLC4X developer, I think it would be great to get a deeper understanding of the reasoning behind the design choices related to STRING handling, especially the 250-character limit and the behavior of S7StringVarLengthTag. Ideally, these issues could be addressed to provide a more robust and flexible solution for working with STRING data in S7 PLCs. I hope this helps to shed some light on the subject. Let me know what you think in the comments. Thanks for reading and happy coding, everyone!
